7.4 Hectare Site Development Area; 28,697 m² Total Building Floor Area (G + 8 Floors)

7.8 Hectare Site Development area; 5,500 m² Religious components; 4,500 m² Educational/Cultural components; 650 m² Commercial components; 1,350 m² Complimentary support facilities

Approximately 2.5 km long shoreline dredging; Width of the zone varies from less than 150m to over 250m and water depth of 5m at low tide for recreational watercraft; Approximately 50 hectares proposed waterfront park include primary and secondary infrastructure for beachfront chalets, luxury restaurants and shops, administration buildings and dredging adjacent to the shoreline.

The project envisions to design sustainable, accessible community space featuring recreational, social, and functional amenities, with environmentally sensitive design, diverse activities, and landscaping that balances aesthetics, usability, and ecological responsibility.

The project aims to design in a 500-hectare food processing and logistics hub under Vision 2030, focusing on animal proteins and fruits and vegetables, with a master plan that integrates markets, production, infrastructure, sustainability, and industrial collaboration to establish a connected food value chain by 2034.

Curve bridge: Based on the natural free flow of a wave, a curved pedestrian bridge is proposed to connect the linear parks. The smooth curve of the pedestrian overhead bridge contrasts with the linearity of the park on either side.; Straight Bridge: Adopting and extending the continuity of the linear park alongside King Abdul-Aziz Road one crossing is achieved by means of a straight linear pedestrian bridge

The main span was to be designed to clear a 40m navigational channel to allow boats up to 15m long and 7m high to pass; Overall, the bridge had 8 no. 45m back spans on one side, then a 60m main span then another 45m back span; Bridge form 2 post tensioned concrete box girders of uniform depth – each carrying 2 lanes of traffic, with inclined piers supporting the spans over water and vertical piers for spans over mud flats.

The Waterfront Beach site planning and design utilize the site's extended contours, bringing distinct functions together under one fundamental to create a coherent architectural presence. The Toilets, Lifeguard Station, Shower area, and Changing Room are seemingly located is easy access by public transport, staff, personnel, and the public

It contains large unique sculptural shade structure which will form the focal point of the park; Large open space to conduct social and corporate events; Opportunity to have future kiosks by investors have been identified; Amenities like seating area, water fountain, waterfront viewing deck has been provided to attract nearby office employees during break time.

197 Total Number of Villas (124 are Type A and 73 are Type B); 166,188 m² Site Area; 76,932 m² Total Covered Area (124 x 392 m² and 73 x 388 m²); Sustainably designed housing with criteria and features like Electrical Energy Savings, Renewable Energy, Water Savings, Smart City Program, and Energy Envelope.

350 single family detached Villas; The floor plans comprise two villa types - A and B, to maximize utilization of the land allocation and to achieve better arrangement in the cul-de-sacs; Each villa type has a further two optional floor plan layouts together with alternate options for exterior elevation treatment.

Approximately 200,000 m² as part of the Mutrafiah District Site Development by the Royal Commission; 279 Total nos. of villas in four different types of modern and classic designs; Including Imam & Moazen Duplex Villa and Daily Mosque.

4,500 m² Site Area; 2,134 m² Total Covered Area; Saudi Modern architectural theme with three (3) main functional areas: the Office and Reception area, the Private Residence area and the Service areas; Courtyards and gardens are also incorporated into the design

Eighty-eight (88) buildings are divided into three categories; Thirteen (13) are Premium offices category (A); Ten (10) are Premium offices category (B) (or Smart); Sixty-five (65) are Standard Category; The renovation will include the Facade and Reception area for each building

2,500 m² Pre-engineered Building, 2,246 m² Total Floor Area; 3 Distict Functional Areas: Kitchen/Service Area, General Dining Hall, and VIP Dining Area; External takeaway Shops/Restaurants - 5 separate locations; Potential expansion of a “Mezzanine Floor” for future needs; 1 Hectare Site Area

Building with 1,000 m² covered area; A Site of 5,000 m²; The Prototypical Fire Station Building for the Royal Commission; Yanbu Fire Department was designed for responding 24/7 and to be equipped with 3 Apparatus / firefighting trucks of different types and sizes to fight against any danger.

1,715 m² (2-Story) Administration Building, which includes Staff Office Area, Computer Labs and Conference Rooms; 1,927 m² (2-Story) Classroom Building, which has 12 nos. of Classrooms, a Library, and Staff Offices; 3,468 m² (1 Story + Mezzanine) 4 Workshops Building; 7,475 m² Total Building Area; 8,873 m² Total Site Area.

Approximately 5,000 m² Single Story floor area; Design Improvements emphasized on adding architectural elements to provide shade and aesthetic value; Landscaping the outdoor area and added more visual spaces to garden to get natural indoor lighting. Also using natural materials and modern comfortable furniture were also prioritized.

Operation and Maintenance (O&M) facility which includes the Support Services Department Building, Warehouse and associated site infrastructure; Design was undertaken fully in house and in 3D Revit and BIM to ensure that everything is fully coordinated and there are no clashes to be resolved on site.

6,000 m² Pre-engineered Warehouse; 2,000 m² Chemical Store; Offices area to accommodate 40 staff (Workstations), with provision for expansion with additional 20 staff; 10 Hectares Site Area

The project is spread across two Sites Named as Cluster 1 and Cluster 2. The Site Are located approximately 35kms away. The Facilities are not interconnected via a road through this project.

The Headquarter Building for the Environment Department is designed to monitor, record, and provide solution for the city environment needs for air, water pollution and solid waste generation; Building with 4,000 m² covered area; A site of 1 Hectare and will have three laboratories – wet chemistry, instrumentation and marine laboratory for testing.

Provides emergency fire and safety training in Eastern Region; 12,609 m² of Total Built-up Area

Security Fence and Security Gates which contain all necessary security features, trucks queuing area, parking area return, waiting and reject lanes, connection to the Smart City system, drum or bollards barriers, connection to the City’s data network, and all wet & dry utilities; Guard Buildings, Security Surveillance Road composed of asphalt, signage, lighting, CCTV, a checking-in system, and all security systems in accordance to HCIS requirements.

The project supports the NTP initiative by improving industrial zone readiness and securing a reliable logistics link to the port. It includes constructing a new bridge to ensure uninterrupted industrial movement between the Bonded Zone and the JCPDI artificial island, with FAEC and the bridge consultant preparing the required design plans.

The project involves creating a coordinated site plan for a villa community and mosque based on villa types, spatial requirements, and site context. It organizes functional relationships, circulation, and land use while integrating privacy through strategic boundary placement and spatial buffering.

The new four-cluster Security Building is designed to integrate with the community, remain visible and accessible, and project a protective presence. Its layout follows crime-prevention principles through transparency, controlled access, strong identity, and clear territorial boundaries. The design enables supports multiple functions, uses modern materials and technologies.

Retal Urban Development Company is launching a major residential project in prime Jubail locations, with BCC handling EPC delivery. The design targets a modern, locally aligned architectural identity that can serve as a model for future Retal communities. Spanning three Royal Commission sites Jalmuda, Yasmeen, and Khozama - the development aims to create an attractive, socially and economically beneficial residential environment.

The Royal Commission mandates the redevelopment of Al-Huwaylat’s 2.2-ha VIP Park, requiring updated layout plans and technical details for new irrigation, landscaping, and integrated softscape and hardscape systems.

The Intermediate School aims to maximize lot limitation and allow for spatial variety by breaking through in a vertical manner within the constrained site. Auxiliary spaces like the food court and multipurpose room are situated on the ground floor, whereas the first floor has specialized art classrooms. This establishes a border for a free and comfortable area, together with a centrally located Open Hall and colorful floor coverings.

The mosque's façade is constructed with stone to demonstrate a modern, strong, and simple expression among the landscape at the site, creating an appropriate contrast with natural stone façade elements and as well as painted hues coatings.

Modern local mosque facade design with a capacity of 559 worshippers combines cultural and spiritual symbolism with climate-responsive features, durable regional materials, and harmonious proportions, all integrated to fit the surrounding urban context while ensuring functionality, privacy, and ease of maintenance.

The local mosque is designed to accommodate 369 worshippers within a narrow plot, balancing orientation towards the Qibla with space for the prayer hall and parking. It integrates with the local urban fabric, respecting scale and views while maintaining visual prominence and preserving privacy and focus, and the overall design facilitates ease of maintenance.
